Precision Access Floor Inlay Conductive ESD Vinyl Tiles

Our Precision Access Floor Inlay Conductive ESD Vinyl Tiles are specifically designed for raised access floor manufacturers, data center contractors, electronics facilities and other static-sensitive environments.

The 600 × 600 mm tile format is suitable for factory lamination onto steel, calcium sulphate and other raised access floor panel cores. Controlled dimensional stability, conductive electrical performance and a specially prepared bonding surface help manufacturers achieve a secure, flat and professional finished panel.

Product Specifications

Product Type: Conductive ESD solid vinyl tile
Electrical Grade: EC conductive grade
Target Application: Factory inlay for steel or calcium sulphate raised access floors
Tile Size: 600 × 600 mm
Thickness: 2.0 mm
Weight: Approximately 3.06 kg/m²
Electrical Resistance: R ≤ 1 × 10⁶ Ω, depending on the applicable test standard
Backside Finish: Rough sanded surface prepared for industrial adhesive bonding

Technical Data

Property	Test Standard	Product Data
Classification and General Requirements
Use Classification	EN 685 / EN 649	Class 34 + 43
NFPA Life Safety Classification	NFPA 101	Class I interior floor finish
Solid Vinyl Tile Specification	ASTM F1700	Pass
Product Requirements	EN 649 / SS-T-312B	Pass
Product Safety Performance	Underwriters Laboratories	Approved for use as electrically conductive flooring in hazardous locations
Physical Properties
Overall Thickness	EN 428 / ASTM F386	2.0 mm
Tile Dimensions	EN 427 / ASTM F536	600 × 600 mm
Weight per Square Metre	EN 430	Approximately 3.06 kg/m² at 2.0 mm thickness
Dimensional Stability	SJ/T 11236-2001 EN 434 / DIN 51962 KS M 3802, by heating	≤0.20% 0.10% <0.30%
Flexibility	ASTM F137	No cracking
Squareness	ASTM F540	600 × 600 mm, ±0.30 mm
Residual Indentation	SJ/T 11236-2001 EN 433 / DIN 51955 ASTM F142	≤0.30 mm 0.03 mm for 2.0 mm thickness; 0.04 mm for 3.0 mm reference thickness <8.0%
Abrasion Resistance	SJ/T 11236-2001 ASTM D1044, CS-10-F wheel, 1500 g ASTM D4060, CS-10-F wheel, 1000 g	Abrasion loss: ≤0.020 g/cm² 2,500 cycles: 0.48% weight loss 5,000 cycles: 0.95% weight loss 7,500 cycles: 1.41% weight loss 10,000 cycles: 1.87% weight loss
Hardness	ASTM D2240	<85
Castor Chair Resistance	EN 425	No damage
Static Load Limit	ASTM F970	1,500 lb/in²
Electrical and ESD Performance
Electrical Resistance	SJ/T 11236-2001 / GB 3007-97 DIN 51953 / EN 1081 IEC 61340 / EOS/ESD S7.1 ASTM F150 / NFPA 99 / UL 779	EC conductive grade R ≤ 1 × 10⁶ Ω Standard-specific conductive range: approximately 2.5 × 10⁴ to 1 × 10⁶ Ω
Static Propensity	AATCC 134 SJ/T 10694-1996	<50 V / <100 V, depending on the applicable test method Chinese standard: <100 V
Static Decay	101C Method 4046, 5000 V to 0 V MIL-B-81705C, 5 kV decay time MIL-B-81705C, 5 kV leakage time GJB 2605-1996	<0.01 second / <0.02 second, depending on the test method 5000 V ±500 V: <2 seconds
Safety, Fire and Environmental Performance
Chemical Resistance	EN 423 / DIN 51958 / ASTM F925	Excellent; test results available
Combustion Performance	DIN 4102 / B 3810 / B 3800	Does not burn or support combustion
Flammability Classification	SJ/T 11236-2001	FV-0, less than 10 seconds
Chinese Fire Classification	GB 8624-1997	GB 8624 Class B1
Smoke Density	ASTM E662 / NFPA 258	Class 1, <450
Critical Radiant Flux	ASTM E648 / NFPA 258 / DIN 51960	Class 1, >1.08 W/m²
Flame Spread Index	ASTM E84 / NFPA 225	<75
Outgassing	ASTM E595	Excellent; test results available
Colour Fastness	ISO 105-B02 / Method 3 / DIN 53389	Grade 5–6
Cleanability / Decontamination	DIN 25415-1 / ISO 8690	Excellent
Water Absorption	ASTM D570	<0.15%
Slip Resistance	EN 13893 / ASTM D2047	0.60 < μ < 0.80; typical μ = 0.62
Repairable	—	Yes
Recyclable	—	Yes

Trade and Supply Information

Minimum Order Quantity: 1 × 20'GP container
Standard Lead Time: Approximately 20 days
Monthly Supply Capacity: Up to 300,000 m²
Available Format: 600 × 600 × 2.0 mm
Test Standards: EN 1081, EN 649, EN 685, ASTM F1700, ASTM F970, ASTM F925, EN 13893 and ASTM D2047

Advantages for Raised Access Floor Manufacturers

Controlled Panel-Fitting Accuracy: The 600 × 600 mm format and controlled squareness of ±0.30 mm help the vinyl surface align accurately with raised access floor panels.
Permanent Conductive Performance: The conductive material is distributed throughout the tile, providing a reliable path for electrostatic discharge without relying only on a temporary surface coating.
High Static Load Capacity: A static load limit of 1,500 lb/in² makes the tile suitable for server racks, communication equipment and other heavy technical installations.
Prepared Bonding Surface: The rough sanded backside improves mechanical adhesion with suitable industrial polyurethane or epoxy adhesives.
Durable and Repairable: The solid vinyl structure provides good abrasion resistance, chemical resistance and localized repair capability.
Suitable for Static-Sensitive Facilities: Recommended for data centers, server rooms, electronic production areas, laboratories, telecommunications rooms and raised access flooring systems.

Important: Electrical resistance values may vary according to the selected conductive formulation, test electrode, environmental conditions and testing method. Final project specifications should be confirmed according to the required standard before production.
